Medical Grade RO Pure Water System 300L/H for Endoscope Cleaning

• Guaranteed Compliance: Produces water that strictly conforms to the microbial and conductivity limits of the WS 507-2016 standard.

• Comprehensive Sterilization: Multi-barrier process including RO membrane, overflow UV, immersion sterilization, advanced oxidation, and terminal filtration.

• Robust Pre-treatment: Multi-stage filtration system designed to handle varying inlet water qualities, ensuring RO membrane protection and longevity.

• Smart & Automated Operation: Features automatic start/stop and timed automatic backwashing for the pre-treatment, reducing manual intervention.

• Stable & Reliable Output: Engineered with high-quality components and an external water tank to guarantee a consistent and reliable supply of pure water.

• IoT-Ready Design: Built with connectivity in mind for potential remote monitoring and control, representing a future-proof investment.

Ensure the highest standard of patient safety and operational efficiency in your endoscopy unit with the YS-RO-(300/500)L/H Medical Pure Water Treatment System. This advanced Reverse Osmosis (RO) water treatment system is engineered specifically for the demanding requirements of medical applications, particularly the cleaning and disinfection of flexible endoscopes. By delivering water that not only meets but exceeds the stringent WS 507-2016 regulation, our system mitigates risk and provides healthcare professionals with absolute confidence in their infection control protocols.

The core of the YS-RO series is its sophisticated single-stage RO system, which effectively removes over 99% of dissolved salts, organic particles, colloids, bacteria, and endotoxins from the incoming water supply. This process is the critical first step in achieving the ultra-pure water quality essential for rinsing sensitive and complex medical devices like endoscopes. To guarantee a continuous and stable supply, the system is equipped with an external water tank, ensuring that pure water is always available on demand during critical disinfection procedures, without fluctuation in quality or pressure.

Water quality is paramount. The YS-RO system is meticulously calibrated to produce water with a microbial limit of ≤10 CFU/100ml and an exceptional electrical conductivity of ≤15 μS/cm at 25°C, a key indicator of purity. This performance is continuously verifiable through the integrated conductivity meter, providing real-time assurance that your water quality remains within the specified compliance range at all times. This commitment to verifiable purity is the cornerstone of preventing biofilm formation and cross-contamination.

Understanding that sterility must be maintained at every point, we have integrated a multi-layered sterilization barrier that goes beyond the RO module. This comprehensive approach includes an overflow ultraviolet (UV) sterilizer that exposes any water in the tank to germicidal UV light, a powerful immersion sterilization module utilizing advanced oxidation processes (AOP) to neutralize microorganisms, and a final terminal filter to capture any potential particulates. This multi-sterilization process creates an uncompromising defense system, ensuring the safety of every liter of water produced.

The system's durability and adaptability are rooted in its robust pre-processing stages. Before water even reaches the RO membrane, it passes through a multi-filtration assembly. This includes a primary 20-inch thick wire-wound sediment filter to remove coarse particles, a secondary choice of a canned coconut shell activated carbon filter (with timed automatic washing) for chlorine and organic matter removal, or a softener resin for hardness reduction, and finally a tertiary 20-inch precision filter to capture any fine suspended solids. This versatile pre-treatment design makes the YS-RO system applicable to regions with different water qualities, ensuring optimal performance and membrane protection regardless of local challenges.

Designed for seamless integration into hospital environments, the YS-RO-(300/500)L/H system features a user-friendly interface and requires minimal operational overhead. Its compact and aesthetically pleasing cabinet design houses all components securely while allowing for easy maintenance access. With straightforward installation requirements and automated operational cycles, the system empowers your staff to focus on patient care, secure in the knowledge that their pure water supply is managed by a reliable and technologically advanced system. Investing in the YS-RO series is an investment in unparalleled water purity, regulatory compliance, and the ultimate safety of your medical procedures.

EQUIPMENT WORK FLOW CHART

EQUIPMENT PARAMETER INFORMATION

EQUIPMENT CHARACTERISTICS AND ADVANTAGES
